Unique Generation Next Features!

Neat & Rust-Free Drip Pan

Plastic drip pan.

Prevents corrosion / rust formation.

Robust Corners

Better designed corner, prevents slippage &

higher static / dynamic performance

Higher Clinch Performance

Clinching position rearranged scientifically on sides. Higher resistance to clinch opening.

Press-Fit Sleeve

Press-fit new clinch sleeve (Optional)

EHS compliant

Ground Conductivity

Specially bolted for grounding / earthing.

EHS compliant.

Safety Guard

Protectors for cage end near drip area.

EHS compliant.

Less Bulging

Long side verticals scientifically aligned, more towards centre. Less bulging

New Composite Pallet

Light weight smartly profiled, good drainability and inter stackability across different IBC’s as well.

Bigger Dog-House Area

Large space for easy connection easy valve replacement on used IBC’s. Reconditioner friendly EHS compliant

New Plastic Pallet

New plastic pallet without in-built steel bridge.Steel reinforcement attached separately. Better performance & eco-friendly recycling possible.

Technical Specifications

DIMENSIONS 330 GAL 275 GAL 135 GAL REGULAR 135 GAL OPTIMA
Foot Prints (L X W) 48" X 40"
(1200 X 1000 mm)
48" X 40"
(1200 X 1000 mm)
48" X 40"
(1200 X 1000 mm)
48" X 40"
(1200 X 1000 mm)
Dimensions (L x W x H) 48" X 40" X 53"
(1200 X 1000 X 1335 mm)
48" X 40" X 46"
(1200 X 1000 X 1155 mm)
48" X 40" X 30"
(1200 X 1000 X 764 mm)
48" X 40" X 27"
(1200 X 1000 X 686 mm)
Cage Profile 7 X 20 6 X 20 4 X 20 4 X 20
Pallet Composite Steel / Full Plastic Composite Steel / Full Plastic Composite Steel / Full Plastic Composite Steel / Full Plastic
Discharge Valve 2 "/ 3" Ball or Butterfly type 2 "/ 3" Ball or Butterfly type 2 "/ 3" Ball or Butterfly type 2 "/ 3" Ball or Butterfly type
Top lid – Plain Fitting & Vented 6" / 9" lid 6" / 9" lid 6" / 9" lid 6" / 9" lid
Gasket Filing Lid EPDM / Viton EPDM / Viton EPDM / Viton EPDM / Viton

Quality Control And Certifications

Elaborate testing facilities are provided at every production facility in-house to ensure stringent testing of manufactured products both on-line and off-line. Products manufactured comply with UN Certification requirements. Different testing and statutory authorities have audited and tested the Products and have accorded their approval across the different regions.
